JSW

JSW NEOSTEEL EDS BARS

  • JSW Neosteel EDS TMT bars are Extra Ductile and Super strong. JSW Neosteel EDS bars are Fe 550D grade, hence are stronger than ordinary TMT bars. Special chemistry and post rolling treatment is used to make these bars more ductile, and thus, more flexible than regular TMT bars.
  • A more ductile, and flexible TMT bar is vital for increased protection of the structure from earthquakes. When a TMT Bar is flexible, it can withstand the shocks of earthquakes much better than an ordinary stiff TMT bar. Higher flexibility allows the TMT bar to bend without breaking at loads, higher than yield strength, but below the tensile strength of the TMT bars. Extra ductility of the JSW Neosteel EDS bars allows them to bend much more without breaking. Thus, offering higher protection to your homes from the shocks of an earthquake.
  • JSW Neosteel EDS facilitates the construction of homes, apartments, buildings and structures designed for earthquake loads applicable as per the IS codes.

Product Properties

Mechanical PropertiesIS 1786:2008 for Fe 550DJSW Neosteel Fe 550DIS 13920:2016*JSW Neosteel EDS 550D
YS (Mpa) (Min)550570550570
UTS (Mpa) (Min)600630600670
UTS/YS (Min)1.081.121.151.15-1.18%
%EL (Min)14.51614.516%-18%
Total %EL at Max force5757
Dia (mm)8-25mm8-25mm
Chemical PropertiesIS 1786:2008 for Fe 550DJSW Neosteel Fe 550DIS 13920:2016*JSW Neosteel EDS 550D
% C (Max)0.250.240.250.23
% P (Max)0.040.040.250.03
% S (Max)0.040.041.150.03
CE (Max)0.0750.0714.50.5
% S+P (Max)0.0120.0120.0120.06
Nitrogen (ppm)0.610.50.611.00

*Ductile Design & Detailing of Reinforced Concrete Structures subjected to Seismic Forces-Code of Practice

6X secure advantages

  • High Strength-550D

  • Extra Ductile bars - High Flexibility

  • Absorbs Higher Earthquake Energy

  • Best Bonding with cement

  • Highest Purity

  • Consistent Quality

Certification

JSW Neosteel Receives Greenpro Certification

JSW Steel is one of the first steel companies in India to get the GreenPro Ecolabel certification for TMT rebars under the brand name JSW Neosteel. JGreenPro is a Type -1 Ecolabel by the Confederation of Indian Industry (CIO- that enables the end-users to choose sustainable products, 'materials, and technologies. It helps in reducing the environmental impacts during the construction, operation, and maintenance of their buildings and factories. Product sustainability is at the heart of the JSW group, and the GreenPro Certification of the Neosteel is one of the significant steps that we have taken to disclose the environmental footprint of the product transparently.
