Plain concrete is strong in compression but weak in tension, making it inadequate as a structural member on its own. Reinforcing concrete with steel (TMT bars), which offers high tensile strength, ductility and strong bonding characteristics, makes the structure reliable.
Steel reinforcement also imparts ductility to brittle concrete, ensuring visible deformation before failure and providing occupants with advance warning.
A home is a once-in-a-lifetime investment built with years of savings. A strong and durable home requires an equally strong foundation, a reliable structural spine and an intact framework. A quality TMT bar provides the required strength, ductility and superior bonding with cement, making it a basic and essential component of home construction.
Yes. Earthquakes transfer large amounts of energy to structures. Ductile materials absorb more energy before fracture than brittle materials. Among steel, brick and concrete, only steel provides the ductility required to withstand seismic forces effectively.
Please refer to the bar bend test video to see the importance of ductility of a TMT bar.
Key parameters include:
JSW Neosteel (Fe500D/550D/600/CRS) TMT bars are manufactured from virgin iron ore using state-of-the-art technology. They offer high purity, superior strength and ductility, consistent quality through HYQST technology, excellent bonding with cement, transparent pricing and free home delivery (within municipal limits). They also conform to Indian, American, British and Australian Standards.
| Properties (Chemical & Physical) | Fe 415 | Fe 500 | Fe 500D | Fe 550D | Significance |
|---|---|---|---|---|---|
| Carbon | 0.3 | 0.3 | 0.25 | 0.25 | Low |
| Sulphur | 0.06 | 0.055 | 0.04 | 0.04 | Low |
| Phosphorus | 0.06 | 0.055 | 0.03 | 0.04 | Low |
| Tensile Yield strength | 415 | 500 | 500 | 550 | High |
| Ultimate Tensile Strength | 485 | 545 | 565 | 585 | High |
| % Elongation | 14.5 | 12 | 16 | 14.5 | High |
Higher levels of sulphur and phosphorus introduce brittleness in a TMT bar, which impacts fatigue resistance and can enhance corrosion — both detrimental to quality.
JSW Steel produces Fe500D, Fe550D, Fe600, and Corrosion Resistant (CRS) grades.
Since required steel area is inversely proportional to yield strength, Fe500D requires fewer bars than Fe415, resulting in savings in beams, columns and overall steel consumption.
Manufacturing involves converting virgin iron ore to molten iron, conversion to steel and continuous casting to form billets, followed by hot rolling and thermo-mechanical treatment to form TMT bars. JSW Neosteel is produced using HYQST technology at JSW Steel’s Vijaynagar and Dolvi works.
Original Neosteel TMT bars feature:
JSW Neosteel TMT bars are sold by length, not by weight. They conform to BIS standards, which specify nominal weight per metre and permissible tolerances.
JSW Neosteel:
A quality TMT bar is defined by consistent quality, superior bonding with cement, low impurities, and the right balance of strength and ductility—achievable only through advanced refining and strict quality control. JSW Neosteel meets all these criteria.
TMT bars account for less than 5% of a home’s construction cost, and the additional cost of JSW Neosteel is under 1% of the total. This small investment ensures long-term safety, durability, and reduced wastage due to breakage during bending and fabrication.
Choosing a quality TMT bar is a proactive safety choice, much like insurance—it matters most during unforeseen events. Earthquakes are unpredictable, and a structure built with ductile, consistently manufactured TMT bars is better able to absorb seismic forces and reduce the risk of damage or collapse.
Carbon improves hardness and tensile strength, but excessive carbon reduces ductility and toughness.
Rusting is the formation of an oxide layer due to air and moisture and has minimal effect on quality. Corrosion is an electrochemical reaction that causes disintegration and uneven erosion, which is detrimental to the product.
Rusted (reddish) bars can be used if the rust can be removed by sanding. Rusting indicates use of virgin iron ore and can improve bonding with cement. To prevent corrosion, TMT bars should be cement washed before stacking and stored away from moisture and porous materials.
JSW Neosteel offers a TMT calculator to estimate the quantity and cost of TMT bars based on base area, number of storeys, building type and seismic zone. Consultation with a structural engineer is recommended.
