JSW Neosteel Fe 550D is a premium grade of high-strength, high-ductility TMT rebars. Whether you’re building a home or a commercial space, JSW Neosteel Fe 550D provides the high strength and superior flexibility needed for lasting safety and peace of mind.
Homes designed by JSW Neosteel 550D consume less steel, up to 15% of steel savings.
Fewer bars are required, reducing labour needs and overall cost.
Fe 550D TMT rebars offer lower steel consumption for the same load-bearing design.
Fewer bars and lighter loads reduce tying and placement time, improving construction efficiency.
Fe 550D based designs can bear higher loads compared to Fe 500D.
Higher strength of Fe 550D TMT provides greater protection from earthquakes.
Columns designed with Fe 550D require a smaller cross-section than Fe 500D, resulting in more usable carpet area.
| Category | Parameter | Fe 550D (As per IS 1786:2008) | JSW Neosteel 550 D |
|---|---|---|---|
| Chemical Composition | % C (Max) | 0.25 | 0.21-0.24 |
| % P (Max) | 0.040 | 0.030 | |
| % S (Max) | 0.040 | 0.030 | |
| CE (Max) | 0.50 | 0.50 | |
| Mechanical Propoerties | Yield Strength N/Mm2 (Min) | 550 | 580 |
| Tensile Strength N/mm² | 600 | 620 | |
| UTS / YS Ratio | 1.06 | 1.06 | |
| % Elongation (Min) | 14.5 | 15 | |
| % T EL (Min) | 5 | 5 | |
| Bend properties | Mandrel diameter upto and including 20 mm (max) | 4d | 4d |
| Mandrel diameter over 20 mm (max) | 5d | 5d | |
| Re-bend properties | Mandrel diameter upto and including 10 mm (max) | 6d | 6d |
| Mandrel diameter over 10 mm (max) | 7d | 7d |
Independent Houses
Apartments
Villas
Bridges
Roads
Metro Stations
Offices
Retail Buildings
